Vacuum Deposition onto Webs, Films and Foils

Vacuum Deposition onto Webs: Films and Foils, Third Edition, provides the latest information on vacuum deposition, the technology that applies an even coating to a flexible material that can be held on a roll, thereby offering a much faster and cheaper method of bulk coating than deposition onto single pieces or non-flexible surfaces such as glass. This technology has been used in industrial-scale applications for some time, including a wide range of metalized packaging. Its potential as a high-speed, scalable process has seen an increasing range of new products emerging that employ this cost-effective technology, including solar energy products that are moving from rigid panels onto cheaper and more versatile flexible substrates, flexible electronic circuit 'boards', and flexible displays. In this third edition, all chapters are thoroughly revised with a significant amount of new information added, including newly developed barrier measurement techniques, improved in-vacuum monitoring technologies, and the latest developments in Atomic Layer Deposition (ALD).

Charles started his working life as an apprentice in mechanical engineering finishing as a toolmaker. He has a degree in Materials Engineering and Masters and Doctorate Degrees by research in vacuum deposition onto polymer webs. He now has accumulated over 35 years experience in vacuum deposition onto webs with the last 15 spent running his own consultancy business. He has published over 85 technical articles and papers, has 5 patents & has run training courses in Asia, Europe and USA. He has written two books 'A guide to roll-to-roll vacuum deposition of barrier coatings' and 'Vacuum Deposition onto Webs, Films & Foils', now into the 2nd edition and contributed chapters on transparent conducting coatings and packaging coatings in two other books. Charles is a Blog editor on behalf of AIMCAL and has a regular column in Converting Quarterly.

1. What is a Vacuum?2. Products using Vacuum Deposited Coatings onto Films or Foils3. Pressure Measurement4. Pumping 5. Process Diagnostics and Coating Characteristics6. Leaks, Water Vapour and Leak Testing7. Mass Spectrometers, Helium Leak Detectors and Residual Gas Analysers8. Substrates, Surface Quality, Cleaning, Adhesion and Adhesion Testing9. Adhesion and Adhesion Tests10. Surface Treatment of Webs and Foils11. Polymer Coatings12. Nucleation, Coalescence and Film Growth13. Pattern Metallization14. The D.C. Glow Discharge or Plasma15. Electron Beam (E-beam) Evaporation16. Thermal Evaporation17. Radiant Heated and Induction Heated Sources18. Chemical Vapour Deposition onto Webs and Foils19. ALD20. Planar Magnetron Sputtering Source Design and Operation21. Planar Magnetron Design Options22. Reactive Deposition, Set-up and Control23. Machine Specification and Build Issues and Risk Analysis Process24. Heat Load onto Webs and Foils25. Process Variables26. Mechanical Design27. Winding Webs in Vacuum28. Machine Building Trends29. System Design30. Hazards31. Troubleshooting32. Final Thoughts
